Dal-bo rollers

Dal-bo new generation rollers for a wide range of applications:

  • post-sowing cultivation,
  • seedbed preparation,
  • as well as ground surface levelling.
  • Rollers are easy to fold and transport. DAL-BO factory provides a 3-year warranty on all metal structures.

Maxi Roll is a new generation Dal-bo roller for a wide range of applications: post-sowing cultivation, seedbed preparation, as well as ground surface levelling. 3-section rollers are easy to fold and transport. Rollers are equipped with 2 types of discs: Cambridge or Crosskill (optional). A specific DUOFLEX-system ensures independent operation of each section by means of hydraulic components, irrespective of the ground surface, achieving 100% even soil pressure. DAL-BO factory provides a 3-year warranty on all metal structures. Automatic transport lock. Jack. Road lights.
500 kg weight per 1 m of the working width. Heavy duty frame profile of 150 x 100 mm. Maintenance free bearings. Chrome shafts of 60 mm. Transport width of 2.5 m.

Optional equipment:
·         crackerboard with spring tines, hydraulic working depth adjustment and mechanical angular (aggressiveness) adjustment;
·         crackerboard tine plates with cracker-pins;
·         stone trays;
·         Scharmuller coupling (K80);
·         hydraulic jack;
·         drawbar (Cat ll / lll);
·         track eradicator;
·         hydraulic brakes;
·         a possibility to equip with a front 2-row harrow (tines of 12 mm) and pneumatic seeder for small seeds (P-Box Speed-Seeder).


DAL-BO Maxi Roll 5-section rollers

Maxi Roll is a new generation 10.3 m and 12.3 m roller from DAL-BO for a wide range of applications: post-sowing cultivation, seedbed preparation, as well as ground surface levelling. 5-section rollers are easy to fold and transport. Rollers are equipped with 2 types of discs: Cambridge or Crosskill (optional). A specific DUOFLEX-system ensures independent operation of each section by means of hydraulic components, irrespective of the ground surface, achieving 100% even soil pressure. DAL-BO factory provides a 3-year warranty on all metal structures. Automatic transport lock. Jack. Road lights. At least 600 kg weight per 1 m of the working width. Heavy duty frame profile of 150 x 100 mm. Maintenance free bearings. Chrome disc shafts of 60 mm. Transport width of 3.0 m. There is a specific 3-D swing link suspension for all sections. Hydraulic brakes (for 12.3 m model).

Optional equipment:

·         crakerboard with spring tines, hydraulic working depth adjustment and mechanical angular (aggressiveness) adjustment;
·        crackerboard tine plates with cracker-pins;
·         stone trays;
·         Scharmuller coupling (K80);
·         hydraulic jack;
·         draw bar (Cat ll / lll);
·         track eradicator;
·         hydraulic brakes (for 10.3 m model);
·         pneumatic brakes.


Dal-bo Front Flex frontal packers

Front Flex is a compact 1-section front mounted packer. It is especially effective if used in combination with a sowing equipment. Packers are equipped with the Cambridge or Crosskill rings. Heavy duty frame together with heavy weight ensure good performance on the field. Linkage design ensures good manoeuvrability and does not increase the pressure on the steering gear while working on the field. Transport width is the same as the working width. DAL-BO factory provides a 3-year warranty on metal frame design. Transport chains. Roll shaft of chromium-plated steel. Automatic transport lock. Jack. Alternatively, it can be used as a rear packer.

Optional equipment:
·         front crackerboard with spring tines, mechanical working depth and angular (aggressiveness) adjustment;
·         changing the height, the angle remains unchanged.


Dal-bo Mini Max Classic rollers
Mini Max Classic is a hydraulic folding roller for a wide range of applications: seedbed preparation, rolling after sowing, as well as rolling of winter crops. Besides, rollers can be used together with a disc harrow. All operations are controlled from the tractor cabin. Hydraulic roller folding is carried out whilst the tractor is stationary. Due to the overlap between each section, a high-quality rolling is achieved even on an uneven ground and when making turns. The weight transfer from the middle section to the side sections is ensured mechanically by means of tensioned springs or hydraulic elements. The specific DUO–FLEX-System ensures independent operation of each section on an uneven ground surface. DAL-BO factory offers a 3-year warranty on frame metal design. Chromium-plated steel shaft of 60 mm for roller discs. Automatic transport lock (for 3- and 5-section models). Road lights (for 3- and 5-section models). 500 kg weight per 1 m. Transport width of 3.0 m. Rollers are equipped with either Cambridge or Crosskill discs.

Optional equipment:
·         road lights (for 4.5, 5.3, 6.3 and 8.3 m models);
·         stone trays (2 pcs);
·         pneumatic brakes;
·         Scharmuller K80 coupling system;
·         linkage / coupling additional devices.

Dal-bo MiniMax XL rollers

MiniMax XL is a hydraulic folding 3-section roller with horizontal roller sections and a low centre of gravity. All operations are controlled from the tractor cabin. Due to the optimum overlap between each section, a good performance quality is achieved along various surfaces of the field, as well as when making turns. The mechanic weight transfer from the middle section to the side sections is ensured by means of 2 tensioned springs, and the specific DUOFLEX-System ensures independent operation of each section. Rollers are equipped with Cambridge and Crosskill discs or water-filled cylinders. DAL-BO factory offers a 3-year warranty on the metal frame. Chromium-plated steel shafts of 60 mm for roller discs. Transport width of 2.5 m.

Optional equipment:
·         hydraulically operated crackerboard with spring tines;
·         mole hill board (for grass models).


Dal-bo Levelflex 2008 front packers

A single-section (1.5 m; 2.5 m and 3.0 m) and 3-section (4.0 m; 4.5 m and 6.0 m) front packer with a heavy duty frame and strong suspension, with an optimum steering geometry. Levelflex is ideal for excellent seedbed preparation. Linkage design significantly minimizes lifting force and keeps stresses on the tractor and front linkage to a minimum. To have a deeper working depth and to crush clods, DAL-BO uses 30° V-profile rings. However, depending on the soil structure and customer demands, it is possible to fit the packers with Cambridge and Crosskill rings, as well as a hydraulically operated crackerboard with spring tines. DAL-BO factory offers a 3-year warranty on the frame design. Automatic transport lock. Chromium-plated shafts of 60 mm for cracker-rings. Specifically designed ring cleaning scrapers. Jack. It is possible to combine V-rings in such a way that 90 cm rings are placed in the middle section but 80 cm rings — in the side sections. Besides, the 1.5 m version can be equipped with a 4.0 m crackerboard.

Optional equipment:
·         front crackerboard with spring tines, hydraulic working depth and angle (aggressiveness) adjustment;
·         changing the height, the angle remains unchanged.
